Cisco Catalyst 9400 Series 48-Port UPOE w/ 24p mGig 24p RJ-45
CiscoCisco Catalyst 9400 Series Multigigabit line card
The Cisco Catalyst 9400 Series 48-Port UPOE Line Card with 24 port Multigigabit ports and 24 10/100/1000 Mbps Ports provides the solution you need to support newer applications such as 802.11ac Wave 2 access points with your existing Ethernet access cabling. Multigigabit switch ports allow automatic negotiation of 100-Mbps, 1-Gbps, 2.5-Gbps, and 5-Gbps speeds on existing Category 5e and 6 cable, and all the way up to 10-Gbps speeds over Category 6 cabling. The Multigigabit Ethernet line card supports Power over Ethernet (PoE), PoE Plus (PoE+), and Cisco Universal PoE (Cisco UPOE) to deliver 15W, 30W, or 60W to the access point. Cisco remains the only vendor that can provide 60W to power downstream devices in a next-generation workspace. So you can power more devices-IP phones, IPTVs, surveillance cameras, virtual desktop clients, and many others-without having to install extra wall or ceiling circuits, while taking advantage of advanced power management capabilities such as Cisco EnergyWise®. You can now realize all of these Cisco UPOE benefits in a single switching platform, while enabling Multigigabit Wi-Fi speeds.
Features
- 48 ports with 24 Multigigabit ports and 24 10/100/1000 Mbps ports
- Speeds of 100/1000 Mbps, 2.5/5 Gbps, and 10GBASE-T on the Multigigabit ports and 10/100/1000 Mbps on the other ports
- Nonblocking up to 1000 Mbps on all ports
- RJ-45 interface on all ports
- Supported on Cisco IOS® XE Software Release 16.6.2 or later
- Cisco UPOE: Capable of up to 60W on all ports in the line card
- Energy Efficient Ethernet 802.3az on all 10/100/1000 ports
- IEEE 802.3bz Multigigabit Ethernet standard on the Multigigabit ports
- IEEE 802.3af/at and Cisco prestandard PoE
- IEEE 802.1AE and Cisco TrustSec® capability in hardware (software roadmap)
- Hardware ready for IEEE1588/802.1AS, Precision Time Protocol (PTP) used for time synchronization across the network for applications such as video and audio (software roadmap)
- L2-4 Jumbo Frame support (up to 9198 bytes)
- Enterprise and commercial: Designed to power next-generation IP phones, wireless access points, wireless base stations, video cameras, virtual desktop clients, and other PoE/Cisco UPOE devices
- Support for campus and branch applications requiring enhanced performance for large file transfers and network backups
- With 10GBase-T technology, get up to 1000Mbps data transfer rate over twisted pair cable
- Enjoy flexibility and scalability with data transfer rate of up to 10 Gbps with 10 Gigabit Ethernet technology
- Supports twisted pair cables for durability and improved signal transfer while ensuring smooth and seamless data transfer
- Total Number of Ports:
- 48
- Interfaces/Ports Details:
- 24 x RJ-45 10GBase-T UPoE LAN,24 x RJ-45 10/100/1000Base-T UPoE LAN
- Compatibility:
Cisco Catalyst 9400 Series Supervisor Engines:
- C9400-SUP-1
- C9400-SUP-1XL
- Product Model:
- C9400-LC-48UX
- Application/Usage:
- Data Networking
- Connector Type:
- RJ-45
- Manufacturer:
- Cisco Systems, Inc
- Product Type:
- Expansion Module
- Manufacturer Website Address:
- http://www.cisco.com
- Media Type Supported:
- Twisted Pair
- Form Factor:
- Plug-in Module
- Ethernet Technology:
- 10 Gigabit Ethernet,Gigabit Ethernet
- Network Technology:
- 10GBase-T,10/100/1000Base-T
- Twisted Pair Cable Standard:
- Category 5e,Category 6
